Description
Features:
- (2) 1/2″ x 4′ oil hose (ZE2204)
- Air Filter/Regulator (ZE1559A2-ASSY)
- Warning! This item is not suitable for flammable liquids
Specifications:
- Air Ratio: 1:1
- Fluid Inlet/Outlet: 1/2″ NPT
- Max Flow: 14 GPM
- Air Inlet Port: 1/4″ NPT
- Body Construction: Polypropylene
- Diaphragms: Buna N
- Balls: Acetal
- Seats: Polypropylene
- Ul Listed: No
- Air Consumption: 16CFM @ 100 PSI
- Bolt Pattern: 4.375″ X 6.75″
- Height: 10.600″
- Max Particle Size: 1/8″
- Suction Lift-Dry: 15′
- Suction Lift- Wet: 25′
